does anyone have the numbers of all the bulbs that are used for 04 elantra?

I know this so far

low beams-H7
High Beams-H1
Fogs-9006

thanks
Gregster


·
Registered
Joined
·
6 Posts
This is from the aftermarket section on the archive site, I think it is specific to the pre 2004 model but there maybe some consistencies.




Bulb Types
Low beam headlight: H7
High beam headlight: H1
Fog lights (GT): H3
Front turn signal/Parking light/Front sidemarker: 2357A
Rear turn signal: 1156A
Tail light/Stop light/Rear sidemarker: 2357
Back up light: 1156
License plate: 168
Trunk/Cargo light: DE3022


·
Registered
Joined
·
5,309 Posts
194 is that lil bulb in the head light thats a pita to get out


·
Registered
Joined
·
575 Posts
From the Sylvania site - not sure how accurate this is though.
2004 HYUNDAI Elantra (5-door model)

Low beam headlamp
H7
H7ST Silverstar High Performance Lighting: the whitest and brightest Halogen
H7CB Cool Blue Halogen Upgrade: White Hot; Super Cool; 100% Street Legal
H7LL Long Life Halogen: Lasts two and a half times longer

High beam headlamp
H1-55W
H1ST Silverstar High Performance Lighting: the whitest and brightest Halogen

Parking light
168

Front turn signal
1156
1156LL Long Life Upgrade: Up to twice the life of the standard lamp

Rear turn signal
1156A
1156AST Silverstar Signal Lighting: Complete the Look: Crisp, Clean, Style
1156ALL Long Life Upgrade: Up to twice the life of the standard lamp

Tail light
2357
2357LL Long Life Upgrade: Up to twice the life of the standard lamp

Stop light
2357
2357LL Long Life Upgrade: Up to twice the life of the standard lamp

High mount stop light
%COM

Fog/Driving light
9006
9006ST Silverstar High Performance Lighting: the whitest and brightest Halogen
9006XV XtraVision Halogen Upgrade: Up to 20% Brighter
9006CB Cool Blue Halogen Upgrade: White Hot; Super Cool; 100% Street Legal
9006LL Long Life Halogen Upgrade: Lasts one and a half times longer

License plate
168

Back up light
1156
1156LL Long Life Upgrade: Up to twice the life of the standard lamp

Front sidemarker
168

Rear sidemarker
168

Map light
DE3175

Dome light
DE3175

Step/Courtesy light
DE3022

Trunk/Cargo area
DE3022


·
Registered
Joined
·
5,309 Posts
cool that really helps sailor

thank you
